Key Word Place of Origin Guangdong, China Brand Name LDSK Place of Origin Guangdong, China Product name RF power amplifier module(GaN) Frequency 720-1020MHz Out power 30W Frequency and Power Customization Support Max Gain 45 dBm Voltage 24-32V Product Size 29.7*131*15.5mm Product Weight 136 g Lead time Quantity(PCS)

Product Parameters 200-250MHz 50W anti drone module for anti drone system Power and Frequnecy support Customzation form 90MHZ- 6700mhz, 10W,20W,30W, 40W, 50w,100W,150W,200W --GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module. --The power amplifier uses domestic core key components and can operate

100W High Efficiency GaN RF Power Amplifier 300-1500MHz Broadband Signal Boost Module for Anti-drone Use Key Features Frequency Range: 300–1500MHz at 100W power Operating Voltage: 28-32V DC Compact dimensions: 170 × 77 × 24.5mm Advanced GaN technology for high efficiency and thermal stability Robust metal housing with thermal management Integrated protection circuits (over-temperature, VSWR) RS-485 and TTL control interfaces Product Description The LDK-TZ-KGN-100W High Power

1.4G 1550-1620MHz 50W GAN anti-drone module Power and Frequnecy support Customzation form 90MHZ- 5.8ghz, 10W,20W,30W, 40W, 50w,100W,150W,200W --The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the modul Parameters Frequency 1.4G 1550-1620MHz Gain 47dBm Size 37.3*112*19.5mm Power 50W Power Flatness 1-1.5dB Supply Current 2.4A Operating Temperature --20~+80ºC

50W GaN RF Power Amplifier Module 400-500MHz for Anti-Drone Systems Product Specifications Customization Customization From 10 To 6700MHZ,10-200W Frequency And Power 400-500MHZ 50W Gain 47dBi Voltage 24-32V Working Efficiency >60% Size 37.3*112*19.5mm Highlight Wide Operating Voltage GaN Module Product Overview Lead Time Quantity (PCS) Lead Time (Days)

Product overview 900mhz 970-1080mhz 30W anti-drone gan module Power and Frequnecy support Customzation form 90MHZ- 5.8g, 10W,20W,30W, 40W, 50w,100W --The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the modul Parameters Frequency 900mhz 970-1080mhz Gain 45dBm Size 29.7*131*15.5mm Power 30W Weight 136g Voltage 30Vdc Range: 24-32V Frequency and Power

Product Description 5725-5850Mhz 100W GaN Amplifier ModuleAppearance and installation instructions: 1. Overall dimensions: 170*94*26.5mm 2. Interface form:① Power supply conditions: +30V power supply: 7W2 (male)②RF input interface: SMA-KFD (optional)③RF output interface: N-KFD④Control interface:a.7W2 (male) socket: The first pin is connected to the power amplifier enable PA_SW (high level 5V/3.3V power amplifier turns on,low level or floating, the power amplifier turns off)b

2400-2500MHz 200W GaN RF Module for Anti-Drone Systems Key Features 2400-2500MHz GaN Module with 200W power output High efficiency operation (≥44%) Compact size: 154.5×73×26.5mm Operates in -10~+55°C temperature range Customization options available Technical Specifications Parameter Value Working Frequency 2400-2500MHz Power Output 200W Supply Voltage DC 28-32V Max Output Power 200W Working Efficiency ≥44% Passband Ripple ≤2dB Weight 900 g Operating Temperature -10~+55ºC

433MHZ 100W 400-500MHZ 428-438MHZ 420-450MHZ 400-450MHZ 100W anti-drone gan module Power and Frequnecy support Customzation form 380MHZ- 5.8G, 10W,20W,30W, 40W, 50W,100W --The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the modul 433Mhz 100W GaN Amplifier Module Appearance and installation instructions: 1. Overall dimensions: 170*94*26.5mm 2. Interface form
